| Omron Hot Stamp Control Box Decal
Indexer Setup |
| The Decal Distance Setup Screen: |
| 1. | Buttons |
|
| Decal Mode |
Takes Operator to the Decal Mode Screen. |
| Main Menu |
Takes Operator to the Main Screen. |
|
| 2. | Settable Values |
|
| Mark Dist | Used
to set the Distance Between Eye Marks on web. |
| Slow Dist | Sets
the Distance before the eyer mark the foil pull motor will run
slow. |
| After Mark |
Sets the Distance the full pull motor will pull after the
photo cell sees the eye mark. |
|
|
 |
|
